To get a competitive price for the Allen-Bradley 1746-NO4V SLC 500 4-Channel Analog Voltage Output Module, you can choose Floating Light Automation as your supplier. We are a reliable distributor to offer high-quality products, and we have inventory to arrange fast delivery.
The Allen-Bradley 1746-NO4V combines industry-proven reliability with exceptional precision, making it the good choice for demanding analog control applications.
Its isolated channel design ensures stable performance in noisy industrial environments, while the flexible power options and easy configuration simplify integration into existing systems.
Backed by Rockwell Automation's global support network, this module delivers long-term value and peace of mind for critical automation processes
|
Parameter |
Value |
|
Module Type |
Analog Voltage Output Module (SLC 500 Series) |
|
Channels |
4 isolated channels |
|
Output Range |
-10V DC to +10V DC (1 LSB resolution) |
|
Max Load Current |
10mA per channel |
|
Max Load Reactance |
1µF |
|
Communication Format |
16-bit two's complement binary |
|
Isolation |
500V DC (field to backplane) |
|
Backplane Current |
55mA |
|
Operating Temp |
32°F to 140°F (0°C to 60°C) |
|
Storage Temp |
-40°F to 185°F (-40°C to 85°C) |
|
Humidity |
5% to 95% non-condensing |
|
Certifications |
UL, CSA, Class I Div 2, Groups A-D |
Process Control: Precise regulation of valves, pumps, and actuators in manufacturing lines
Motion Control: Positioning of servo drives and variable frequency drives (VFDs)
Instrumentation: Signal generation for test and measurement equipment
Building Automation: HVAC control, lighting management, and energy monitoring systems
Industrial Monitoring: Calibration and control of analog sensors and transducers
System Compatibility: Works with all Allen-Bradley SLC 500 chassis and processors
Terminal Block: Removable screw terminal block for easy field wiring
Configuration: Software-configurable via RSLogix 500 programming environment (no DIP switches)
Mounting: DIN rail or panel mount in standard SLC 500 I/O racks
We supply two product conditions for 1746-NO4V: brand new factory sealed original stock and fully tested refurbished units.
New Original Modules: 12-month global warranty, factory packaging intact
Refurbished Tested Units: 6-month functional warranty, 100% bench tested before shipment
Complete SLC 500 series I/O modules, CPU processors and power supplies are available in spot inventory.
Bulk order discounts and professional technical selection support are offered for system integrators and factory maintenance buyers.
Reach out to our team for customized quotation and integration consultation.
A: Generally, no. The 1746-NO4V is classified as a "simple" or "non-configurable" I/O module. The output range is determined by the data value written to the module's output image word.
The module features DIP switches used to select between external power and backplane power.
A: It is recommended to install the module away from AC or high-voltage DC equipment to minimize electrical noise interference.
Install it away from the system power supply; regarding ambient temperature, installation in the chassis closest to the bottom of the enclosure is recommended.
A: Use a multimeter to measure the voltage at the output terminals. Write known values (such as 0, 16382, or 32767) to the output and verify that the output voltage corresponds to 0V, 5V, or 10V, respectively.
Test under load to ensure the output remains within specifications.
