SICK DT50-P2113

The SICK DT50-P2113 belongs to the DT50 series of distance sensors, which uses mature time-of-flight (ToF) measurement technology to achieve non-contact high-precision distance detection.

It is designed for complex industrial application scenarios, with excellent anti-interference ability and environmental adaptability, and can work stably in harsh conditions such as dust, vibration and temperature fluctuations.

As a PNP output model with a 2m sensing range, DT50-P2113 has been widely used in logistics sorting, automated warehouse, packaging production line, automotive manufacturing and other fields, helping enterprises achieve automated detection, positioning and measurement functions.

If you are looking for a supplier with ample stock and can offer fast delivery, Floating Light Automation is a good choice. We are an authorized distributor.

Core Technical Specifications

Comparison with Other DT50 Series Models

SICK DT50 series has multiple different models to adapt to different application requirements.

The following is a comparison of DT50-P2113 with other common models to help you choose the most suitable product:

From the comparison, it can be seen that DT50-P2113 is the most cost-effective mass model in the DT50 series, covering the most commonly used 2m range, and matches the PNP output logic adopted by most modern industrial control systems.

It is the preferred choice for most standard automation applications.

Recommended Matching Combinations

1. Standard Installation Matching

For users who need to quickly install and use, we recommend matching the SICK STE-1204 mounting bracket and M12 4-pin pre-wired connector cable.

The STE-1204 bracket can realize multi-angle adjustment of the sensor, which is convenient for on-site debugging.

The pre-wired cable avoids the trouble of on-site wiring, and the length can be selected from 2m, 5m and 10m according to the site requirements.

This combination can save more than 30% of on-site installation time.

2. Outdoor Harsh Environment Matching

If the sensor needs to be used in outdoor or highly polluted environments, we recommend adding a PBT protective cover for DT50 series and matching an oil-resistant and low-temperature-resistant cable.

The protective cover can effectively block splashing water, oil mist and dust, further extend the service life of the sensor, and will not affect the normal emission and reception of the laser signal.

3. Multi-sensor Networking Matching

For scenarios that require multiple sensors to work at the same time, such as logistics sorting lines with multiple detection points, we recommend matching DT50-P2113 with DT50-P2114 (with analog output) to realize the combination of switching trigger and continuous distance measurement.

At the same time, DT50 series sensors have a built-in anti-interference synchronization function, which can support up to 10 sensors to work adjacent at the same time without mutual interference; no additional controller is required.

Typical Application Scenarios

· Logistics automated sorting system: detect the position and size of packages to trigger sorting actions

· Automated three-dimensional warehouse: detect the entry and exit position of pallets, and realize accurate positioning of stackers

· Packaging production line: detect the height of stacked packaging boxes to ensure that the number of stacking meets the standard

· Automotive parts processing: detect the positioning of workpieces on the production line to trigger processing actions

· Conveyor system: detect the presence of materials to prevent material jamming and empty conveyor operation

Our Source Guarantee

Floating Light Automation has maintained a strategic partnership with SICK for more than 8 years, and is an authorized industrial products distributor covering the Asia-Pacific and North American markets.

For the SICK DT50-P2113 sensor, we maintain a stock of more than 120 units in our three warehouses located in Singapore, Los Angeles and Shanghai, which can achieve 48-hour delivery for most global regions.

All products we sell are 100% original new from SICK official production lines, we provide complete factory test reports, product qualification certificates and traceable serial number query services.

Each DT50-P2113 we supply comes with 12 months of official warranty, and we provide replacement services for non-human damage quality problems within 30 days of delivery.

Over the past 3 years, we have supplied more than 1500 units of DT50 series sensors to more than 400 industrial customers around the world, with a 99.6% on-time delivery rate and customer satisfaction of over 98%.

If you need large-volume orders of more than 50 units, we can coordinate with SICK's regional warehouse to arrange priority shipment, and the maximum monthly supply capacity can reach 300 units, which can fully meet the demand of large-scale automation project construction and OEM assembly.

After-sales Service Support

All DT50-P2113 sensors purchased from Floating Light Automation can enjoy free pre-sales technical consultation, we can provide you with product selection suggestions, installation drawing reference and wiring guidance according to your project.

During the warranty period, if there is any product quality problem, we provide free replacement and maintenance services, and we can provide spare sensor support within 7 days for urgent projects to ensure that your production line will not be shut down for a long time.

If you need to get a quotation, check inventory or arrange sample order, please contact our customer service team through the contact information on this website, we will reply to you within 24 working hours.

FAQ

Q: How do I set the response time?

A: The SICK DT50-P2113 offers three selectable response time settings:

Fast: 15 ms (suitable for high-speed dynamic measurement)

Medium: 30 ms

Slow: 80 ms (suitable for static measurements or applications requiring high stability)

A faster response time increases measurement speed but may affect stability. A longer response time results in more stable measurements. You should strike a balance between speed and stability based on your specific application.

Q: Does the DT50-P2113 require a warm-up period?

A: Yes, the warm-up time is ≤ 15 minutes. After powering on, it is recommended to allow sufficient time for the sensor to reach thermal stability before performing precision measurements to ensure optimal accuracy.

Q: How well does it resist ambient light interference?

A: It has an ambient light immunity of 40,000 lx, which is equivalent to the illuminance level of direct sunlight outdoors on a clear day.

It performs well under standard indoor factory lighting, as well as outdoors on cloudy days or in areas without direct sunlight.

However, avoid pointing the laser receiver window directly at strong light sources, such as the sun or high-power floodlights.
