Siemens 6ES7315-2AH14-0AB0

As an authorized automation component distributor for Siemens products, Floating Light Automation maintains long-term stable supply chains with original factory stock and authorized third-party inventory partners.

We currently hold over 120 units of Floating Light Automation in our global warehouses located in Germany, the United States and Singapore, enabling same-day shipping for most global orders and a maximum lead time of 3 working days for out-of-stock replenishment.

All products are fully tested before shipment, with a 12-month global warranty and original factory certification to ensure 100% authenticity and reliable performance.

Key Technical Specifications

The 6ES7315-2AH14-0AB0 CPU is packed with industrial-grade features tailored for demanding automation environments, the core specifications are as follows:

· Working memory: 256 KB (128 KB for code, 128 KB for data)

· Process performance: Typical instruction processing time of 0.1 µs per bit operation, supporting up to 1024 digital I/O points and 128 analog I/O channels

· Communication interfaces: Integrated 1x MPI (Multi-Point Interface) and 1x PROFIBUS-DP interface, supporting maximum 12 Mbps baud rate, direct connection to distributed I/O stations and HMI panels

· Backplane current consumption: 500 mA from the 5 V backplane bus

· Power supply: 24 V DC nominal input, with overvoltage and reverse polarity protection

· Operating temperature range: 0°C to 60°C, suitable for standard industrial cabinet environments

· Mounting: Compatible with standard S7-300 35 mm DIN rail mounting

Comparison With Similar S7-300 CPU Models

To help you select the most suitable CPU for your application, below is a comparison of 6ES7315-2AH14-0AB0 with other common models in the S7-300 series:

From the comparison above, we can see that the 6ES7315-2AH14-0AB0 offers the best balance of performance and cost for most medium-scale automation projects. If your application does not require native PROFINET communication, this model will deliver sufficient processing power at a more competitive price point than the 6ES7315-2EH14-0AB0 variant, while outperforming smaller CPUs like the 6ES7314 to support more complex control logic and distributed I/O architectures.

Recommended Matching Modules & Accessories

The SIMATIC S7-300 system uses a modular design, allowing you to configure the hardware according to your specific application requirements. We have summarized the most common matching configurations for 6ES7315-2AH14-0AB0 based on years of field application experience:

1. Power Supply Modules

The 6ES7315-2AH14-0AB0 draws power from the S7-300 backplane bus, so a matching system power supply is required. For most standard configurations we recommend:

· Low power configuration (less than 4 expansion modules): 6ES7307-1EA01-0AA0 (5 A, 24 V DC output)

· Medium power configuration (5-8 expansion modules): 6ES7307-1EA00-0AA0 (5 A, stabilized output)

· High power configuration (more than 8 expansion modules): 6ES7307-1KA02-0AA0 (10 A, 24 V DC output)

Floating Light Automation stocks all these power supply models, with over 200 units of the most common 6ES7307-1EA01-0AB0 available for immediate delivery.

2. Digital I/O Modules

For general digital signal input and output, the most popular matching modules for 6ES7315-2AH14-0AB0 are:

· 32-channel 24 V DC digital input: 6ES7321-1BL00-0AA0

· 32-channel 24 V DC digital output: 6ES7322-1BL00-0AA0

· 16-channel relay output: 6ES7322-1HH01-0AA0

All of these modules are compatible with the PROFIBUS-DP distributed I/O architecture supported by 6ES7315-2AH14-0AB0, and can be mounted either centrally on the same DIN rail as the CPU or remotely in distributed stations.

3. Analog I/O Modules

For process control and measurement applications, we recommend the following common analog modules to pair with 6ES7315-2AH14-0AB0:

· 8-channel analog input (voltage/current configurable): 6ES7331-7KF02-0AB0

· 4-channel analog output: 6ES7332-5HD01-0AB0

· 8-channel thermocouple input: 6ES7331-7PF01-0AB0

4. Communication & Other Accessories

To expand the communication capabilities of the 6ES7315-2AH14-0AB0, you can add an Ethernet communication processor module such as 6GK7343-1EX30-0XE0 to enable TCP/IP communication for remote data access and MES system integration. For memory expansion, the CPU supports up to 8 MB MMC memory cards, with the most common model being 6ES7953-8LL31-0AA0.

Typical Application Scenarios

The 6ES7315-2AH14-0AB0 has been widely used in various industrial fields due to its reliable performance and moderate cost. Common application scenarios include:

· Automated assembly lines in the automotive manufacturing industry, controlling process flow and robot coordination

· Packaging and sorting lines in the food and beverage industry, supporting continuous 24-hour operation

· Batch processing control in the fine chemical and pharmaceutical industry, meeting the requirements of precise sequential control

· Material handling and storage systems in logistics and warehousing, controlling stackers and conveyor systems

· Retrofit projects for existing production lines, replacing older S5 series PLCs to upgrade control performance

Our Supply Capability & Inventory Guarantee

As a leading global distributor of industrial automation components, Floating Light Automation has established a deep cooperative relationship with Siemens and official channel suppliers, ensuring a stable supply of original authentic Siemens SIMATIC products including the 6ES7315-2AH14-0AB0.

Our current supply capability guarantees are:

· Regular stock: 120+ units stored in multiple global warehouses, ready for same-day shipment after order confirmation

· Bulk order support: We can fulfill bulk orders up to 500 units per month, with a maximum lead time of 15 working days for large orders directly from the Siemens factory

· Obsolete product support: Even though the 6ES7315-2AH14-0AB0 has been in production for many years, Siemens still maintains formal production supply, and we also maintain a safety stock of over 50 units to support long-term after-sales maintenance and retrofit projects

· Authentication guarantee: All units are accompanied by original factory inspection reports and serial number verification, which can be queried and confirmed through the official Siemens website

After-sales Service & Support

When you purchase 6ES7315-2AH14-0AB0 from Floating Light Automation, you will get the following comprehensive after-sales support:

· 12-month global warranty, covering any product quality issues, with free replacement or repair service

· Free pre-sales technical consultation to help you confirm the configuration and matching modules for your project

· Fast global shipping, with DHL, FedEx and sea freight options to meet different delivery time requirements

· Support for 30-day unreasonable return for unused and unopened products

If you need a quotation, check inventory or have any technical questions about 6ES7315-2AH14-0AB0, please contact our sales team through the website, we will reply to you within 24 working hours.
