Omron E5DC-RX2DSM-000

Designed and manufactured by Omron, a global leader in industrial automation technology, the Omron E5DC-RX2DSM-000 combines a compact footprint, powerful control logic, and an intuitive user experience, making it perfectly suited to the rigorous standards of modern production lines.

As an authorized distributor of Omron industrial components, Floating Light Automation offers rapid delivery and comprehensive after-sales technical support, whether you require a single unit for maintenance or a bulk order to support large-scale production.

Core Product Specifications

The Omron E5DC-RX2DSM-000 is a digital temperature controller powered by 24V AC/DC, belonging to the Omron E5DC series of compact temperature control products.

Mounting dimensions: 48mm × 24mm; suitable for confined control panel spaces, integrated automation equipment, and compact machinery.

Input types: Supports thermocouples (Types K, J, T, E) and platinum resistance thermometers (Pt100).

Temperature measurement range: -200°C to 2300°C.

Equipped with a 14-bit A/D conversion module, it achieves a measurement accuracy of ±0.3% of full scale and features a high-speed sampling cycle of 100ms, ensuring real-time response to temperature fluctuations.

In terms of output, the E5DC-RX2DSM-000 adopts NPN open collector output for control signals, supporting PID self-tuning control mode.

The built-in advanced PID algorithm can automatically adjust control parameters according to load changes, avoiding temperature overshoot and maintaining stable temperature control within ±0.1℃ under steady-state conditions.

The product also has built-in over-temperature alarm and sensor fault alarm functions, which can trigger alarm output automatically when abnormal conditions occur, effectively protecting equipment and production safety.

Environmental specifications:

Front panel protection rating: IP66

Operating temperature: 0–55°C

Operating humidity (non-condensing): 25–85%

Certified by CE and UL; complies with international safety standards.

Comparison with Similar Models of E5DC Series

To help customers choose the right product, we compared the E5DC-RX2DSM-000 with other common models of the same series as follows:

From the comparison results, the Omron E5DC-RX2DSM-000 has outstanding cost performance in the NPN output type with 24V power supply.

Compared with the relay output E5DC-QX2ASM-000, the NPN output of E5DC-RX2DSM-000 has a longer service life, supports high-frequency switching, and is more suitable for continuous production scenarios with frequent temperature adjustments.

Compared with the current output E5DC-CX2ASM-000, it meets the needs of independent temperature control without additional signal output, and the price is more advantageous, which is the first choice for most independent temperature control units.

Recommended Matching Solutions

According to different application scenarios, we provide the following matching recommendations for the E5DC-RX2DSM-000:

· Small packaging machinery temperature control system

Match Omron E2C proximity sensor and G2R-1-SN DC24 relay.

The E5DC-RX2DSM-000 is responsible for sealing temperature control, the proximity sensor detects the position of the packaging bag, and the relay controls the heating action.

This solution has compact structure, stable performance and is suitable for mass production of small packaging equipment.

· Food processing oven temperature control

Match PT100 platinum resistance temperature sensor (Omron E52-PT1D temperature probe).

Pt100 has higher accuracy in the medium and low temperature range of 0-300℃, which can meet the strict temperature control requirements of food processing, and the E5DC-RX2DSM-000's PID self-tuning function can avoid temperature fluctuation affecting food processing quality.

· Industrial heating furnace experimental platform

Cooperate with Omron CP1E-N20DR-D PLC to form a combined control system.

The E5DC-RX2DSM-000 is responsible for real-time temperature control, and the PLC is responsible for process flow control and data recording, which can meet the requirements of experimental scenarios for multi-segment temperature adjustment and data traceability.

· Plastic injection molding machine nozzle temperature control

Match K-type thermocouple (Omron E52-CA1D temperature probe).

K-type thermocouple can adapt to the high temperature environment above 300℃ of injection molding nozzle, and the high-speed sampling of E5DC-RX2DSM-000 can respond to temperature changes during injection molding in time to ensure the stability of injection molding temperature.

Common Application Fields

The Omron E5DC-RX2DSM-000 is widely used in various industrial automation fields, including packaging machinery, food processing equipment, plastic injection molding machinery, semiconductor manufacturing equipment, laboratory test equipment, wood processing machinery, pharmaceutical production equipment and other scenarios.

Its compact size can save valuable control panel space, while the stable and reliable performance can meet the requirements of 24-hour continuous operation of industrial production, which is recognized by a large number of industrial equipment integrators and end users.
